機車電纜WDZ-DCYJB/3-150mm2

適用范圍 　　

     機車電纜WDZ-DCYJB/3-150mm2適用于額定電壓3kV及以下的鐵路客車用電線電纜用的配電系統、控制系統、信號系統的電器裝置用電纜.特別適用于窄小空間以及有低煙、無鹵、阻燃要求的場合。



執行標準

　　 機車電纜WDZ-DCYJB/3-150mm2執行GB / T 12528一2008



使用特性

    1、額定電壓(文流)分為:500V、 750V、1500V、 3000V。

    2、電纜線芯允許的長期工作溫度:
 125℃交聯聚烯烴混合物絕緣  ·················································································125℃
 125℃薄壁型電纜用聚烯烴混合物絕緣·····································································125℃

 150℃薄壁型電纜用聚烯烴混合物絕緣·····································································150℃

    3、電纜***低使用環境溫度:
 交聯聚烯烴混合物絕緣·········································································-40℃
 薄壁型電纜用聚烯烴混合物絕緣···············································································-60℃


    4.耐Ell特性代號:
 安裝在無礦物油和燃料油污染處································································1
 安裝在受礦物油污染，但無燃料油污染處《耐礦物油).....................................................2
 安裝在受礦物油污染和嫩料油污染處(耐礦物油和燃料油)...............................................3


     5.電纜敷設的允許彎曲半徑:
 電纜直徑(D)為20m m及以下時應不小于6D。
 電纜直徑(D)為20m m及以下時應不小于8D。

電纜結構

型號及名稱

型號	名稱	芯數	標稱截面
WDZ一DCYJ一125	銅芯耐熱125℃交聯聚烯烴絕緣無鹵低煙阻燃鐵路客車用電線電纜	1	1~4mm2
WDZ一DCYJ/2一125	耐礦物油銅芯耐熱125℃交聯聚烯烴絕緣無鹵低煙阻燃鐵路客車用電線電纜	1	0.75~300mm2
WDZ一DCYJ/3一125	耐礦物油和燃料油銅芯耐熱125℃交聯聚烯烴絕緣無鹵低煙阻燃鐵路客車用電線電纜	1	0.75~300mm2
WDZ一DCYJB一125	銅芯耐熱125℃薄壁型電纜用聚烯烴絕緣無鹵低煙阻燃鐵路客車用電線電纜	1	0.5~6mm2
WDZ一DCYJB/2一125	耐礦物油銅芯耐熱125℃薄壁型電纜用聚烯烴絕緣無鹵低煙阻燃鐵路客車用電線電纜
WDZ一DCYJB/3一125	耐礦物油和嫌料油銅芯耐熱125℃薄壁型電纜用聚烯烴絕緣無鹵低煙阻然鐵路客車用電線電纜
WDZ一DCYJB一150	銅芯耐熱150℃薄壁型電纜用聚烯烴絕緣無鹵低煙阻燃鐵路客車用電線電纜
WDZ一DCYJB/2一150	耐礦物油銅芯耐熱150℃薄壁型電纜用聚烯烴絕緣無鹵低煙阻燃鐵路客車用電線電纜
WDZ一DCYJB/3一150	耐礦物油和洪料油銅芯耐熱150℃薄壁型電纜用聚烯烴絕緣無鹵低煙阻燃鐵路客車用電線電纜
WDZ一DCKYJE一125	銅芯耐熱125℃交聯聚烯烴絕緣及護套無鹵低煙阻然鐵路客車用電線電纜	2~48	0.5~2.5mm2
WDZ一DCKYJE/B一125	銅芯耐熱125℃高強度薄壁聚烯烴絕緣交聯聚烯烴護套無鹵低煙阻燃鐵路客車用電線電纜
WDZ一DCKYJEPI一125	銅芯耐熱125℃交聯聚烯烴絕緣鍍錫銅絲編織屏蔽交聯聚烯烴護套無鹵低煙阻然鐵路客車用電線電纜
WDZ一DCKYJEPI/B一125	銅芯耐熱125℃高強度薄壁聚烯烴絕緣鍍錫銅絲編織屏蔽交聯聚烯烴護套無鹵低煙阻然鐵路客車用電線電纜
